TB-10 Tech

Characteristics

Length: 475 mm
Width: 282 mm
Weight: 3,6 Kg./Teja
Units/sq.m.: 10,4 Uds.
Useful length: (Batten distance) VARIABLE 390 - 410 mm
Units per ml eave line: 4,25 - 4,54

Minimum pitch recommended 30% – 17º (*)
Useful width 235-220 mm
Pallet info 210 units / 771 Kg.
Pallet info for container 140 units / 514 Kg.
Minimum order 5 roof tiles

Range BorjaTECH.

Technological evolution in the large sizemixed tile format. We have made improvements in the manufacturing and development process to give the tile even greater definition and make it completely watertight. Ideal for architectural projects anywhere in the world.

Adapts to various batten spacings.

Longitudinal and transverse double fit.
Curved tile aesthetic.

Approximate values: If the roof tiles are installed on battens, the useful length must be calculated on site.
A tolerance of ± 2% is allowed on the dimensions of the roof tiles according to UNE – EN 1024.

Type: Double lateral overlapping and double Lengthinal overlapping. Installation must comply with Code of practice for the design and fixing of roofs with clay roofing tiles for the region and Tejas Borja specifications.

(*) Check pitch pannel according to the roof length and the geographical area.
